B. An AC Cross Flow Fan pushes air over these Infrared Quartz Bulbs. Cross Flow Fans create a
wide flow of air using a cylindrical-shaped impeller. Air is drawn inside the Infrared Heater, flows
along the circumference of the chamber and over the Infrared Quartz Bulbs, and is blown out
laterally creating a uniform flow of warm air.
C. The Infrared Heater has a Delay Start Function which controls the AC Cross Flow Fan. The
purpose of the Delay Start Function is to allow the Infrared Quartz Bulbs to heat up before the fan
begins to circulate the air flow. In addition, the AC Cross Flow Fan will continue to circulate the
airflow after the power is turned off to circulate the warm air from the Infrared Heater cooling the
unit down.
D. The air flow exits through the front of the Infrared Heater. It travels from the Diathermanous
Copper Plate. The Diathermanous Copper Plate is constructed from red copper making it
advantageous for efficient thermal conductivity. It is a resourceful material in reflecting the
infrared rays.
E. The LED Digital Display is a convenient, stylish, and modern way to display the set temperature
and time. This attractive addition compliments the Infrared Heater, in that, it simplifies and makes
controlling the unit easy. Operating the heater is logical and can be done on the unit itself or by
remote.
Unpacking the Infrared Heater
1. First, check the carton to make sure there are no obvious damages that may have occurred
during shipment.
2. Open the Infrared Heater packaging and remove the heater by sliding it from the box. You may
want to gently and cautiously turn the entire box upside down letting the heater slowly slide out.
3. Remove all the protective materials from the heater. It may be a good idea to keep the protective
materials and packaging for storage during the off-season.
Operating Instructions
Visually inspect the Infrared Heater for any damages before operation. Do not operate the
heater if any damages are detected. Contact your dealer immediately.
NOTE: “UP” and “DOWN” arrow buttons on the control panel and remote control have
dual function capabilities.
Adjust TIME / TEMP with up arrow or adjust HI / LOW settings.
4
