Westward Operating Instructions and Parts Manual
3
INTERMEDIATE CHEST
Maintenance
Lubricate the lock with graphite annually. Lubricate the ball bearing slides with grease twice annually.
Warranty
LIMITED ONE-YEAR WARRANTY
Should this product fail to perform satisfactorily due to a defect or poor workmanship within ONE YEAR from the date
of purchase, return it to the place of purchase and it will be replaced, free of charge. Incidental or consequential
damages are excluded from this warranty.
Replace the lock parts
To release lock set:
1. Remove the spring clip①.
2. Remove lock② and hook ③ in sequence.
To reinstall lock set:
1. Insert lock ② through the roundhole.
2. Connect spring clip① and hook ③ insequence.
