Westward 5M460C - Page 4

5M460C, 5M471B, and 5M472C
4
Westward Operating Instructions and Parts Manual
Hydraulic Crane Jacks
Manufactured for Grainger International, Inc.
100 Grainger Pkwy., Lake Forest IL 60045 U.S.A.
For Repair Parts, call 1-800-323-0620
24 hours a day - 365 days a year
Please provide following information:
-Model number
-Serial number (if any)
-Part description and number as shown in parts list
Item Description 5M460C Part No. 5M471B Part No. 5M472C Part No. Qty.
1
2
3
4
5
Oil Filler Plug
Filter
Seal
Release Valve Assy
Release Lever
5905-00100-100
G931-07015-000
5905-00056-000
BL80-16001-000
BL80-16002-000
5905-00100-100
G931-07015-000
5905-00056-000
BL80-16001-000
BL80-16002-000
5905-00100-100
G931-07015-000
5905-00056-000
BL80-16001-000
BL80-16002-000
1
1
1
1
1
6
7
8
9
10
Screw
Washer
Pump Piston
Hydraulic Cartridge
Handle Sleeve
5107-05016-000
BL80-14002-000
BL80-14101-000
BL80-15000-000 (2 pcs)
BL80-13000-000
5107-05016-000
BL80-14002-000
BL80-14101-000
BL80-15000-000
BL80-13000-000
5107-05016-000
BL80-14002-000
BL80-14101-000
BL80-15000-000
BL80-13000-000
1
1
1
1
1
11
12
13
14
15
Handle
Air Motor
Piston, Air Motor
Air Inlet Swivel
Hose Assembly
BL80-20000-000
A27010-0001
A27010-0008
A27010-0002
A20060-0005
BL80-20000-000 BL80-20000-000 1
1
1
1
1
16
*
**
Air Control Valve
Repair Kit
Repair Kit
A20060-0007
BL800S-034
A27010-0000
BL400S-034 BL800S-034
1
1
1
Figure 2 - Repair Parts Illustration
A
1
E
5
11
B
2
7
13
C
3
H
8
14
D
4
I
9
16
F
6
12
J
10
15
