TECHNICAL SPECIFICATION
FREQUENCY RESPONSE: 20Hz - 20kHz +3dB
THD: <0.03%
HUM AND NOISE: -94dB
LEVEL CONTROL RANGE: 0~6dB
INPUT IMPEDANCE: 10K ohm (BALANCED)
OUTPUT IMPEDANCE: <600 ohm (BALANCED)
MAX OUTPUT LEVEL: 22dBm (BALANCED)
MAX: INPUT LEVEL: 22dBm (BALANCED)
FREQUENCY RANGE: 50Hz - 10kHz
HIGH CUT FILTER: 15kHz 12dB/OCTAVE
LOW CUT FILTER: 40Hz 12dB/OCTAVE
CD HORN EQUALISATION: 3kHz
POWER CONSUMPTION: 12 VA
POWER: 95V ~130 VOLTS AC, 50 - 60Hz
190V ~250 VOLTS AC, 50 - 60Hz
DIMENSIONS: (HEIGHT . WIDTH . DEPTH) 483 x 160 x 44 mm / 19 x 6.3 x 1.7 inches
WEIGHT: 2.7Kg (6lbs)
-
POWER SUPPLY FOR WPG SERIES ELECTRONIC CROSSOVER.
UK DISRIBUTED UNITS COME WITH FITTED MAINS PLUG, 250V
13 AMP, BS1363/A I.S.40/A
WPG SERIES PROFESSIONAL E
