Wheelock SAFEPATH SCSP-4RP User Manual

9-19
Section 9-11 - Remote Microphone Station (RMS-2)
Wheelock, Inc. Part Number: RMS-2R (Red) 105475
The Remote Microphone Station (RMS-2) is designed to used with the Single Circuit SAFEPATH
®
Panel.
It provides a means of emergency voice announcements from a remote location. Only 1 Remote
Microphone Station connection is available on the SAFEPATH
®
Panel. A single RMS-2 module can be
connected, or an Auxiliary Input Module (AIM-3) can be connected, allowing as many as three RMS-2
modules to be used.
Additional Information is available on the RMS-2 Installation Instructions P83270.
Specifications:
Power Input Voltage: 20-31VDC
Audio Output Level: 1.05Vrms
Output Impedance: 600 Ohms
Input Current: 50 mA
3. Press microphone button
and speak into microphone
1. Turn key to ON position
OPERATING INSTRUCTIONS:
MANUAL
OFF
ON
SYSTEM STATUS
NORMAL
AUTO
TROUBLE
REMOTE MICROPHONE
STATUS
2. Select zones
Figure 9-11
Remote Microphone Station (RMS-2)
