Whirlpool ACE 100 IX - Building-In

25
Minimum distance
850
550
Min.
450
560
450
20
455
595
5
27
368
74
3
61
BUILDING-IN
Please check the minimum measures necessary to the proper installation of the appliance.
The coffee maker must be installed in a column unit, which must in turn be fixed to the wall.
ventilation passageway
Fasten metal strip using
the two screws.
