6 TRONIC MODEL SETTINGS ( Installer )
POWER SUPPLY : 200 – 250 VAC.
POWER CONSUMED : 4 VA
OPERATIONAL TEMPERATURE: 0 / 60 °C
OPERATIONAL HUMIDITY: max 90 % without condensation
NORMS: The control unit is designed and manufactured in observance of the
European norms in vigor regarding electrical safety and electromagnetic compatibility.
Particularly the following:
EN 61000-6-3 : Emissions for residential and commercial environments
EN 61000-6-2 : Immunity for industrial environments
EN 61000-4-11 : Immunity to supply micro-interruptions
EN 60335-1 : Low voltage safety directive
ZERO CROSSING : The relay which powers the tank’s electrical resistance is equipped with the “ zero crossing “
function which synchronizes the switching of this relay, both in closing and in opening, with the voltage supply’s
passing to zero, both for 50 Hz and 60 Hz frequencies. In this manner, use of the relay’s contacts is significantly
reduced.
Clamp Connection for top-loading models
1 – 2 Control Unit Power Supply, 230 VAC
3 – 4 Boiler temperature sensor
5 – 6 Tank temperature sensor
10 Break-tank pressostat
11 Reserve input
12 Micro hood
13 Tank pressostat, closed over level
14 Common inputs
15 Boiler resistance remote control switch coil
16 Tank resistance, max. 10 Amp.
17 -
18 -
18 B.TANK Rinse pump (machine type 4)
19 Wash pump ( max. 1 HP )
20 Rinse electrovalve + pressure increase pump
21 Drain pump ( max. 0.75 HP ) Optional
22 Output power supplies, 230 VAC phase
Parameter Description Range Preset
P0 Drain cycle time 1-5’ 1
P1 Boiler temperature 60-95°C 82°C
P2 Tank temperature 40-65°C 55°C
P3 Rinse duration 10-40’’ 13”
P4 Boiler stop option YES/NO 0 NO
SETTINGS
During the first startup, arrange for the setup or the adjustment of the functions/parameters indicated
hereafter:
