Whirlpool ER2MHKXPL02 - Cabinet Parts

CABINET PARTS
2
For Models: ER2MHKXPL02
(Stainless−VCM)
8199367
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
2314273 Service &
Wiring Sheet
2302166 Energy Label
2302037 Use & Care Guide
2225413 Customer
Instructions
Following May Be Purchased
DO−IT−YOURSELF
REPAIR MANUALS
677969 Do−It−Yourself
Manual, Ref./Fzr.
2 2189410 Hinge (Top)
3 2166108 Roller, Front (2)
4 489464 Screw, 8−18 x 1/2
5 489385 Clamp, Tube
(Water Supply Line)
6 8281265 Screw
7 489427 Screw
9 489341 Washer
10 2179826 Rivet
11 3400504 Screw
12 549193 Clamp, Cord
15 489497 Screw
16 2183972 Hinge, Center
17 2183854 Shim, Hinge
Center
20 2254473 Hinge Butt
24 Fitting, Water Tube
(Not Serviced)
27 2183998 Hole Plug (6)
28 Seal, Front
(Not Serviced)
30 Seal, Rear
(Not Serviced)
35 2201017 Corner Filler (2)
36 2254315 Grille
(Includes
Illus. 37)
37 2189356 Clip, Grille (2)
38 487576 Washer
40 2213363 Cover, Hinge
41 Rail, Center
(Not Serviced)
44 2302358 Cover, Unit
45 Cabinet (Not a
Serviceable Part)
