24
4. Remove the three (3) screws securing the
hinge plate to the front of the dishwasher
inner door panel. (Fig. 3-31)
5. Open the door slightly. Hold onto the door
assembly. With the counterbalance spring
removed, the door will drop open easily.
6. Lift the door up to disengage it from the
hinge pin (Fig. 3-30, INSET) and then
carefully pull the hinge plate from the in-
ner door panel.
SCREWS
Fig. 3-31
