Whirlpool UXT4030AD - Wiring Diagram

10
WIRING DIAGRAM
0.35 ±10% A
21 ±10% Watts
46.9 ±10% Ohms
37.2 ±10% Ohms
C10
SE113C
Motor Characteristics
Power Supply 120 VAC
Frequency 60 Hz
Amperage
Wattage Rating
Motor Resistance
White - Red
White - Black
Light Switch
On - Off
Motor Switch
Low - Off - High
BK BK
WH
RD BK BR
BK
GND
Ground
Screw
LN
BR RD WH WH WH
Speed 2
Speed 1
Common
