Whirlpool W10329360A - Door Removal & Replacement; Drawer Front Removal

7
Drawer Front Removal
A. Loosen 4 Door Bracket Screws
A
Drawer Front Replacement
Door Removal & Replacement
Top Hinges
A. Hinge Cover Screw
B. Top Hinge Cover
C.
5
/ 16 " Hex-Head Hinge Screws
D. Top Hinge
A. Hinge Pin Cover
C. Hinge Screws
B. Bottom Hinge
Bottom Hinges
A
B
C
1
2
B
A
C
D
Connections
A
B
A. Wiring Plug
B. Water Line Connection
