12
3. Release the Cover tabs.
4. Releasing the On board Connectors.
IMPORTANT
# Be careful when using the Multimeter measuring probes, as they may damage the
Connector terminals.
# Be careful when removing the electronic board connectors, as they are latched.
Remove them at right angles with no side movements
To Next Page
