3
Refrigerator Bins
The bin on your refrigerator door are adjustable to meet your
individual storage needs.
■ The center bin position can be adjusted in two xed points.
To remove the bin pull it up by applying force on both bottom
sides where the bin is engaged to the door lug. Install it in the
other position by pressing it down until the door lug is fully
engaged to the bin.
■ Free up shelf space with four gallon door bins that t items
like gallon milk.
Freezer Storage Compartments
Pullout Freezer Shelves and Drawers
Easily store large or small items in the pull out freezer tray shelves
NOTE: To open the trays to it’s full extend please refer to the
space required at the refrigerator side to open the doors at the
required minimum angle. Find detailed information in the
“Installation Instructions”.
Full width removable rack
The Full width removable rack is located in the freezer
compartment below the ice bin tray.
To remove the full width removable rack:
■ Remove the content of the ice bin and from the full width
removable track.
■ Remove the ice bin from the freezer tray.
■ Remove the freezer tray with bin from the freezer
compartment pulling it out.
■ On the back of the tray, pull the wire up and backwards to
disengage the rack from the tray in the area shown in the
picture below.
Gallon Bin
Standard Bin
Freezer
Shelves
C
A
B
A. Full width removable rack
B. Third Tier
C. Ice Bin
