CONTROL PANEL PARTS
4
For Models: WTW6600SW2, WTW6600SG2, WTW6600SB2
(White) (Biscuit) (Black)
W10119755
Illus. Part
No. No. DESCRIPTION
1 W10112113 Control Unit
Assembly,
Machine & Motor
2 8565260 Gasket, Valve Tray
3 Tray Assembly,
Console (Includes
Items 2 & 4)
8565304 White
8565306 Biscuit
8565305 Black
4 8565259 Gasket,
Console/Tray
5
W10059320 Valve, Log
Assembly
6 Knob, Control
8574957 White
8574958 Biscuit
8574959 Black
7 8564290 User Interface
8
W10004990 Screw, 6−20 x 1.2
9 Console
W10070060 White
W10070070 Biscuit
W10070080 Black
10 8564265 Cover, Rear−
User Interface
11
W10003770 Screw,
6−19 x 1/2 (3)
12
W10022060 Nut, Push−In (3)
13
W10045100 Harness, Upper
14 8565324 Screw,
10−16 x 1.75
15 8281136 Screw, 8−18 x 3/4
16 3407203 Cord Assembly,
Power
17 98460 Nut, Push−In (2)
18 3976300 Washer, Water
Inlet Hose
(1−1/16 x 5/8)(4)
19 Hose, Water Inlet
8571377 Blue Coupler
8571378 Red Coupler
20 488649 Screw, Power
Cord Ground
21 3407187 Harness,
Thermistor
