Page 10 | 1-800-343-9463
CWSK.PS4000.B
082015
Strip the blue and black wires from the previous
step.
Crimp a red female disconnect labeled 3 onto the
black wire from the previous step.
Secure the red female disconnect from the previous
step to the #3 terminal on the DOB relay.
Crimp a closed end terminal onto wire 12 and the
other stripped wire from step 23.
23
24
25
26
To Next Page
