Secure the yellow female disconnect from the
previous step to the #1 terminal on the DOB relay.
Zip tie wires 7, 10, 11 & 12 from the Cold Weather
Start Kit box to the fan shroud as shown.
Zip tie the wires going into the N1 and H1 lever
connectors as shown.
Tuck the wires into the electrical box and zip tie as
shown.
31
32
33
34
