Page 18 | 1-800-343-9463
CWSK.PS4000.B
082015
Route the 24v control wires into the Cold Weather
Start Kit electrical box.
Connect the 24v control wires to the grey and
purple wires using the wire nuts provided.
Zip tie wires as shown.
Secure the Cold Weather Start Kit box to the top of
the coil using the ½” self taping screws provided.
(Using screws or mounting locations other than
the ones specied, may result in a punctured coil.)
55
54
56
57
