Whistler XP200i User Manual

WHISTLER inverters convert low voltage, direct current (DC) to
115 volt alternating household current (AC). The AC output is
called “modified sine wave”. See “Operating Principles” section
for more information.
Depending on the model and its rated capacity, WHISTLER inverters
draw power either from standard 12 volt automobile and marine
batteries or from portable high power 12 volt sources.
1. AC Output Sockets
2. Inv+USB/Off/USB
3. USB Power Ports
4. Power On LED
5. Power Input
Terminal Black = Negative
6. High Speed Cooling Fan
7. Power Input
Terminal Red = Positive
8. Power Port Power Cord
(XP400i Only)
9. Battery Clamps
(XP400i Only)
10. Hardwired 12V Adapter Power Cord
(XP200i Only)
FEATURES DESCRIPTION
3
2
3
4
7
6
5
8
9
10
1

Whistler XP200i Specifications

General

Brand	Whistler
Model	XP200i
Category	Inverter
Language	English
