DAB Submersible Pump Installation Instructions 2013 rev 1 6
SINGLE PHASE 240 VOLT CABLE SELECTION
TESLA
4.4
5.9
8.2
10.5
15.3
240V MOTOR PSC
kW (HP)
0.55
(0.75)
0.75
(1.0)
1.1
(1.5)
1.5
(2.0)
2.2
(3.0)
Metric
Cable
Stranding
Area
mm2
metres
metres
metres
metres
metres
7/0.50
1.5
67
49
36
29
19
7/0.67
2.5
123
91
67
53
36
7/0.85
4.0
197
146
106
85
58
7/1.04
6.0
296
218
159
126
87
7/1.35
10
496
366
268
213
147
7/1.70
16
791
585
426
339
235
THREE PHASE 415 VOLT CABLE SELECTION
TESLA
1.8
2.3
3.3
4.2
5.7
8.0
9.6
13.5
16.8
415V MOTOR
kW (HP)
0.55
(0.75)
0.75
(1.0)
1.1
(1.5)
1.5
(2.0)
2.2
(3.0)
3.0
(4.0)
4.0
(5.5)
5.5
(7.5)
7.5
(10.5)
Metric
Cable
Stranding
Area
mm2
metres
metres
metres
metres
metres
metres
metres
metres
metres
7/0.50
1.5
240
185
133
104
77
55
46
33
27
7/0.67
2.5
442
340
245
192
142
101
84
61
49
7/0.85
4.0
710
546
395
308
229
161
135
98
79
7/1.04
6.0
1062
817
590
462
342
241
202
147
118
7/1.35
10
1784
1372
991
775
575
405
339
246
198
7/1.70
16
2843
2186
1579
1236
917
646
541
392
315
