FMC+ Loopback Connectivity Card User Guide www.whizzsystems.com 11
version 1.0 March 15, 2017
HA [00:21] To HB [00:21]
HA00_N_CC F5 HB00_N_CC K26
HA00_P_CC F4 HB00_P_CC K25
HA01_N_CC E3 HB06_N_CC K29
HA01_P_CC E2 HB06_P_CC K28
HA02_N K8 HB01_N J25
HA02_P K7 HB01_P J24
HA03_N J7 HB02_N F23
HA03_P J6 HB02_P F22
HA04_N F8 HB03_N E22
HA04_P F7 HB03_P E21
HA05_N E7 HB04_N F26
HA05_P E6 HB04_P F25
HA06_N K11 HB05_N E25
HA06_P K10 HB05_P E24
HA07_N J10 HB07_N J28
HA07_P J9 HB07_P J27
HA08_N F11 HB08_N F29
HA08_P F10 HB08_P F28
HA09_N E10 HB09_N E28
HA09_P E9 HB09_P E27
HA10_N K14 HB10_N K32
HA10_P K13 HB10_P K31
HA11_N J13 HB11_N J31
HA11_P J12 HB11_P J30
HA12_N F14 HB12_N F32
HA12_P F13 HB12_P F31
HA13_N E13 HB13_N E31
HA13_P E12 HB13_P E30
HA14_N J16 HB14_N K35
HA14_P J15 HB14_P K34
HA15_N F17 HB15_N J34
HA15_P F16 HB15_P J33
HA16_N E16 HB16_N F35
HA16_P E15 HB16_P F34
HA17_N_CC K17 HB17_N_CC K38
HA17_P_CC K16 HB17_P_CC K37
HA18_N J19 HB18_N J37
HA18_P J18 HB18_P J36
To Next Page
