1．Start by removing the bottom hinge from
the bottom of the freezer. Unscrew the two
screws from the bottom hinge. Remove the
foot from opposite side. Slide the door down,
away from the hinge pin located on the top of
the door.
2. Remove the top hinge cover from door
first. Then unscrew the two screws from top
door hinge and replace on the other side.
3. To install the top hinge on the left side of
the appliance, secure the two screws
through the hinge and into the top of the
appliance. Slide the door back on to the top
hinge. Ensure the door is face up. Replace
the top hinge cover on the top hinge by
pressing down until it clicks into position.
4. Screw the bottom hinge into place on the
new side. Replace the foot on the other side.
5. Ensure the door is aligned horizontally
and vertically and that the seal is closed on
all sides before finally tightening the bottom
hinge. Re-adjust the leveling feet.
