8
Installation
WHEEL INSTALLATION
This portable freezer comes with optional wheel castors for mobility.
1. Carefully place the freezer on its side on a flat surface.
2. Unscrew the 4-ø5x screws from both bottom left side legs of the freezer and remove. The bottom right
side legs of the freezer are not required to be removed. (Fig. 1)
3. Install the two wheel castors with plates at the bottom left side of the freezer. Tighten these castors by
using the 8-ø5x screws provided.
4. Install the two wheel castors with brakes at the bottom right side of the freezer. Tighten these castors by
using the 8-M5 screws provided.
Fig. 1
Front Side
Freezer Door
Hinge
Bottom Left Side Legs
4-ø5x screws
8-M5x screws
8-ø5x screws
Wheel castor
with lock
Fig. 2
Wheel castor
with plates
Freezer Door
Handle
LOCKING THE WHEELS
This portable freezer is provided with two (2) wheel castors with lock function for stability.
1. To lock the freezer in place, step and push the black pedals all the way down until the wheels are se-
cured.
2. To release, lift from the under side of black pedals.
WARNING: Do not attempt to move the freezer while the wheels are locked to avoid damage.
