Step 30: When the bed is closed check to
see if the gap on either side is the same. If
it looks right skip this step. If the gap is not
right, meaning that the Bed Box is too close
to the side board or even touching it at the
top on one side it will need to be adjusted.
The procedure will require the bottom of
the bed to be moved slightly to the left or
right depending on which top corner is too
close. If the bed is too close on the top
right side for instance, the right side (bot-
tom) will need to be slid to the left slightly.
Have one person push the bed at the bottom
with his feet while the second person pulls
at the opposite bottom side.
Gap
Gap
Page 16
Push bed
over at the
bottom to
align
Step 31: Attach the Bed
Handles provided using the pre
drilled holes in the two center
panels
