Williams 2001622 - Page 18

Replacement Parts List
Fireplace-Look with Logs
Key No.
Description
3502522
3532522
3552522
3502922
3532922
3552922
3502521
3532521
3552521
3502921
3532921
3552921
5002522
5032522
5052522
5002922
5032922
5052922
5002521
5032521
5052521
5002921
5032921
5052921
6502522
6532522
6552522
6502922
6532922
6552922
6502521
6532521
6552521
6502921
6532921
6552921
1 Panel Side Right K000204 K000204 K000205 K000205
K000206 K000206
2 Bottom Panel K000229 K000229 K000230 K000230 K000231 K000231
3 Hearth
K000462 K000462 K000463 K000463 K000464 K000464
4 Cabinet Bottom
K5000-6003 K5000-6003 K5000-6004 K5000-6004 K5000-6019 K5000-6019
5
Rear Corner Brace
K7003-6097 K7003-6097 K7003-6097 K7003-6097 K7003-6097 K7003-6097
6
Wire Assembly
P500409 P500409 P500416 P500416 P500416 P500416
7
Top Panel
K000232 K000232 K000233 K000233 K000234 K000234
8
Combustion Chamber
K000435 K000435 K000440 K000440 K000445 K000445
9
Burner
P501620 P501620 P501621 P501621 P501622 P501622
10
Control Bracket
K000147 K000147 K000147 K000147 K000147 K000147
11
Burner Orifice
P500336 P500351 P500347 P500330 P500327 P500343
12
Orifice Fitting
P500086 P500086 P500086 P500086 P500086 P500086
13
Manifold Pipe
P500087 P500087 P500088 P500088 P500089 P500089
14
Gas Control Valve
P323011 P322660 P322660 P323011 P323011 P322660
15
Thermostat
P322016 P322016 P322016 P322016 P322016 P322016
16
Electrode Igniter
P322276 P322276 P322276 P322276 P322276 P322276
17
Pilot & Generator Assembly
P501617 P501618 P501618 P501617 P501617 P501618
18 Window Assembly
K000450 K000450 K000451 K000451 K000452 K000452
19 Vent Safety Switch
P500472 P500472 P500406 P500406 P500118 P500118
20 Heat Shield
K7003-6370 K7003-6370 K7003-6371 K7003-6371 K7003-6372 K7003-6372
21 Back Plate
K000226 K000226 K000227 K000227 K000228 K000228
22
Shield Cover
--K7011-6030 K7011-6030 K7011-6031 K7011-6031
23 Cabinet Top
K000223 K000223 K000224 K000224 K000225 K000225
24 Panel Side Left
K000207 K000207 K000208 K000208 K000209 K000209
25 Inlet Duct
K7000-6022 K7000-6022 K7000-6022 K7000-6022 K7000-6022 K7000-6022
26
Front Log
P500678 P500678 P500679 P500679 P500680 P500680
27 Rear Log Set
P500674 P500674 P500675 P500675 P500676 P500676
29 Stainless Steel Screw (2 Required)
P103200 P103200 P103200 P103200 P103200 P103200
30 Bracket
7A189 7A189 7A189 7A189 7A189 7A189
31 Manual Spark Igniter
P285500 P285500 P285500 P285500 P285500 P285500
Note: Screws, bolts and washers are standard hardware items and may be purchased locally.
