Wilson Electronics 311229 User Manual

5
Mounting the Antenna with
Spring
3-Way Antenna
Mount with hardware
Side Exit
Adapter
Spring
Mast Extension
If installing with the Spring, disassemble
the 3-Way Mount and use disc washer
and nut (provided) to mount the antenna
with Spring as shown.
add thread
locker
add thread
locker
Remove nut & shake
proof washer
Remove bolt &
plastic washer
Mount disc washer with lip
in the DOWN position
Fasten nut with lip in
the UP position

Wilson Electronics 311229 Specifications

General

Brand	Wilson Electronics
Model	311229
Category	Antenna
Language	English
