Signal Booster
Outdoor
Antenna
Inside Panel
Antenna
Figure 2
INCORRECT INSTALLATION
Never point antennas toward each other
Point antennas away from each other
Signal Booster
Outdoor
Antenna
Inside Panel
Antenna
Figure 1
CORRECT INSTALLATION
