WilTec 50 l User Manual

PARTS LIST
No Description Qty No Description Qty
1
Screw M6x55
4 33
Engine Cover
1
2
Cylinder Head
1 34
Screw M5x103
4
3
Air Filter
1 35
Engine Cover
1
4
Cylinder Head Gasket
1 36
Clip
1
5
Valve Cover
1 37
Connector
1
6
Alumina Gasket
1 38
Cover
1
7
Valve Cover Gasket
1 39
Nut M8
1
8
Valve Flap
2 40
Washer (8mm)
1
9
Cylinder
1 41
Capacitor
1
10
Allen Screw M8x25
2 42
Rubber Washer
4
11
Cylinder Gasket
1 43
Distributor
1
12
Piston Ring
1 44
Tube
1
13
Piston
1 45
Screw M5x14
6
14
Piston Pin
1 46
Drain Pipe
1
15
Clip
2 47
Nut M10
2
16
Screw M5x16
4 48
Washer (8mm)
2
17
Oil Cover
1 49
Washer (10mm)
2
18
Oil Level Indicator Seal
1 50
Sleeve (10mm)
2
19
Oil Level Indicator
1 51
Wheel
2
20
Screw M6x10
1 52
Bolt Screw (10mm)
2
21
O-Clip 5.6x1.8
1 53
Pedestal
1
22
Rubber Gasket
1 54
Drain Valve
1
23
Piston Rod
1 55
Tank
1
24
Allen Screw M8x22 (links)
1 56
Screwing Rp 1/2
2
25
Crankshaft
1 57
Nut Rp 1/4
1
26
Crankcase
1 58
Pressure Regulator
1
27
Protective Ring
1 59
Outlet Valve
2
28
Bearing 6204
1 60
Pressure gauge for regulated pressure
1
29
Coil
1 61
Safety Valve
2
30
Rotor
1 62
Pressure gauge for boiler pressure
1
31
Bearing 6202
1 63
Outlet Valve
1
32
Wavewasher
1
© by WilTec Wildanger Technik GmbH Seite 21
http://www.WilTec.de
http://www.aoyue.eu
http://www.teichtip.de
