Cleaning the ignition head
1. If it becomes difficult to ignite the flame, the ignition head tip may be dirty.
2. In this case, it is necessary to clean the ignition head tip.
3. The ignition head tip is located next to the burner opening (see the illustration below).
№
Name
1
Burner
2
Ignition Head Tip
4. To ensure proper functioning, remove food residues between the ignition head tip and the
burner.
5. Use fine sandpaper or emery paper to clean the ignition head tip and the burner edge.
6. Check the distance: The ignition head tip should be about 4–6 mm from the burner edge. This
is the ideal distance for reliable ignition.
№
Name
1
Burner
2
Ignition head tip
3
4–6 mm
Storing the gas grill
• The gas grill may only be stored indoors if the gas cylinder has been removed.
• If the grill will not be used for an extended period, it should be covered with a protective cover.
