© by WilTec Wildanger Technik GmbH Item 50150 and more Page 4
http://www.WilTec.de
http://www.aoyue.eu 09 2021-1
http://www.teichtip.de
Resistance
• The maximum temperature of the pumped liquid should not exceed +35 ℃ in continuous oper-
ation.
• The transport of aggressive fluids (acids, bases, etc.) as well as of abrasive substances (for
example sand) must be avoided.
Electrical connection
• The electrical connection is made to an earthed socket 230 V ~ 50 Hz. Fuse min. 6 A.
• The motor is protected from overcharge and blockage with the help of the built-in thermal motor
protection. When overheated, the pump motor is automatically switched off by the thermal pro-
tection; after cooling down, the pump automatically re-starts.
Mains connection
The pond pump that you have purchased is already equipped with a protection plug. The pump is meant
to be connected to a 220/230 V~50 Hz safety socket. Make sure that the socket is sufficiently protected
(min. 6 A) and fully functional. Plug in the plug, the pump is operational.
Note:
Installation
Place the pump beneath the water surface, making sure that no water can penetrate into the socket.
Figure 1
The pump is installed the following way: either in a stationary position with a fixed pipeline or in a sta-
tionary position with a flexible pipeline.
Use as submerged pump (see Fig. 1)
• Submerge the pomp completely into the pond to allow it to fill with water.
• In order to protect the pump from obstruction, place it above the pond mud.
• In case a filter sponge is included, install it in order to keep the intake of the pump free.
• The pump is operated by plugging the plug in the socket.
