1 inlet & outlet connection 7 UVC lamp 17 input cover
1-1
inlet & outlet connection O-
ring
8 decoration strip 18 sucker
2 primer button 9 main body 19 dirtiness entrance connection
3 switch 9-1 main body O-ring 20 output curvy bar
4 cover 10 ballast part 21 bend connection-1
4-1 Impeller cover 11 pipe 22 bend connection-2
4-2 Impeller set 12 draining skep cover 23 spray bar
5-A Buckle on the cover 13 draining skep 24 spray bar cover
5-B Buckle on the main body 14 input curvy bar
6 quartz glass tube 15 joint of dirtiness entrance
6-1 Quartz glass O-ring 16 input bar
PS: PART 6, PART 6-1 AND PART 7 ONLY FOR HW-702B HW-703B HW-704B
PS: PART13 QTY IS 3PCS FOR HW-702A HW-703A HW-702B HW-703B
PART 13 QTY IS 4PCS FOR HW-704A HW-704B
SPECIFICATION
Item HW-702A HW-702B HW-703A HW-703B HW-704A HW-704B
Voltage
220-240V/50HZ
Power(W)
18W 24W 35W 30W 55W 45W
Output(L/h)
1000L/h 1000L/h 1400L/h 1400L/h 2000L/h 2000L/h
UVC power(W)
/ 9W / 9W / 9W
