Parts Listing – Model 4200A Belt and Disc Sander Assembly
Ref # Part No. Description Qty.
1 5508427 Bracket 1
2 5511833 Square Nut, M10 1
3 50510801 Spring 1
4 5051091 Sleeve 1
5 5051131 Collar 1
6 5508431 Shaft with Collar 1
7 5051151 Cap 1
8 TS-2361051 Lock Washer, M5 2
9 TS-1513051 SHFS, M5 x 25 2
10 5051721 Hand Wheel 1
11 5511818 FH Screw, M5 x 6 4
12 TS-1550071 Flat Washer, M10 2
13 5508432 Tilting Table 1
14 5508450 Hand Knob 4
15 5508429 Belt Adj. Knob, M10 1
16 5511824 Drive Screw, M2 x 5 5
17 5508437 Stop Lock 1
18 5511828 Groove Pin, M5 x 45 1
19 5051351 Tilting Scale 1
20 TS-1523011 SHSS, M6 x 6 2
21 5511827 Groove Pin, M4 x 8 2
22 5051331 Segment 1
23 5511725 4200 Arbor Pulley 1
24 TS-1504061 SHCS, M8 x 30 4
25 TS-2361081 Lock Washer, M8 4
26 5508433 Trunnion 1
27 TS-1550061 Flat Washer, M8 9
28 TS-2361081 Lock Washer, M8 9
29 TS-1490041 Hex Cap Screw, M8 x 25 3
30 5508435 Stud, M10 1
31 TS-1550071 Flat Washer, M10 4
32 5508436 Acorn Nut and Handle 1
33 TS-2361061 Lock Washer, M6 3
34 TS-1482031 Hex Cap Screw, M6 x 16 3
35 5508439 Preload Bushing, M54 1
36 BB-6205ZZ Ball Bearing, 6205ZZ 1
37 5508438 Bearing Housing 1
38 TS-2210951 Hex Cap Screw, M10 x 140 2
39 5051421 Key, 5 x 5 x 70 1
40 5508441 Drive Shaft 1
41 5051451 Key, 5 x 5 x 35 1
42 4200A-042 Key, 5 x 5 x 55 1
43 BB-6204ZZ Ball Bearing, 6204ZZ 1
44 5051471 Retaining Ring, S20 1
45 VB-A59 V-Belt, A59 1
46 TS-2245081 SHFS, M5 x 8 4
47 5508444 Belt Guard Assembly 1
48 4200A-048 Warning Label 1
49 TS-1540071 Hex Nut, Full, M10 5
50 5508446 Stop Pin 1
51 5508447 Base 1
52 TS-2210801 Hex Cap Screw, M10 x 80 4
53 5515292 Flat Washer, M10 8
54 TS-2361101 Lock Washer, M10 6
55 5051841 Garnet Belt 1
Ref # Part No. Description Qty.
56 5508455 Deflector Plate 1
57 TS-2361051 Lock Washer, M5 2
58 TS-1513021 SHFS, M5 x 12 2
59 5508454 Drive Drum Guard 1
60 5508456 Dust Deflector 1
61 TS-2361101 Lock Washer, M10 3
62 TS-1491021 Hex Cap Screw, M10 x 20 3
63 5508457 Platen 1
64 TS-1514011 SHFS, M6 x 12 2
65 5051601A Side Guard 1
66 TS-1540231 Hex Nut, M24 1
67 9058121 Lock Washer, Ext., M24 1
68 5051981 Spacer 1
69 5051971A Drive Drum 1
70 5508458 Clamp Ring 1
71 4200A-071 Spacer 1
72 5051031 Tension Lever Pin 1
73 5051021 Belt Tension Lever 1
74 BB-6202ZZ Ball Bearing, 6202ZZ 2
75 5508461 Idler Drum Shaft with 1
Lock Nut 1
76 TS-2342121 Hex Nut, Nylon Lock M12 2
77 5508460 Bearing Lock Nut 1
78 5051591A Idler Drum Guard 1
79 5508462 Stud 3
80 5508463 Clamp Bar 2
81 5052121 Bottom Guard 1
82 TS-2361061 Lock Washer, M6 4
83 5052061B Idler Drum Spacer 2
84 5508459 Idler Pin Bracket 1
85 TS-0367061 Roll Pin, 1/4" x 1-1/4" 2
86 5052001 Block 2
87 5052061A Idler Drum 2
88 5508434 Pointer 1
89 5508451 Clamp with Pins 2
90 4200A-090 Roll Pin, M6 x 45 4
91 5508453 Disc Guard 1
92 TS-2239551 SHCS, M10 x 55 2
93 5051741 Pointer 1
94 TS-1523031 SHSS, M6 x 10 2
95 5051641 Disc, Aluminum 1
96 5051631 Garnet Disc 1
97 5051681 Trunnion 2
98 TS-1490041 Hex Cap Screw, M8 x 25 4
99 5508449 Table 1
100 5051701 Tilting Table Scale 1
101 5052271 Deluxe Miter Gauge 1
102 TS-1550071 Flat Washer, M10 2
103 TS-1482032 Hex Cap Screw, M6 x 17 4
104 4200A-104 Label, Name 1
105 4200A-105 Label, Direction 2
106 TS-1482081 Hex Cap Screw, M6 x 40 2
107 TS-1540041 Hex Nut, Full, M6 2
108 TS-1523021 SHFS, M6 x 8 1
109 4200A-109 Label, Warning 1
110 TS-152704 Allen Wrench, 4mm 1
To Next Page
