Windchaser PACR9 - ACCESSORIES FOR VENTING; Wall Venting Accessories; Window Venting Accessories

This air conditioner is a perfectly mobile self-contained appliance. All the components are
located inside the appliance. It is supplied with various accessories:
Figure D - Accessories for Venting through a Wall
1) Exhaust Hose
2) Exhaust Hose Connector
3) Nozzle Fitting Cover
4) Nozzle Fitting
5) Wall
If you need to extend your exhaust hose, it may be extended up to 5’ only
using 4” P.V.C. pipe available at your local hardware store. DO NOT USE
DRYER TYPE EXHAUST HOSE TO LENGTHEN. ..EXHAUST.
D
E
Figure D - Accessories for Venting through a Window
1) Exhaust Hose
2) Exhaust Hose Connector
3) Nozzle Fitting Cover
4) Nozzle Fitting
5) Adjustable Window Panel
212
3
4
5
34
2
1
2
5
Adjustable
Window
Panel
4
