Windsor 10090240 - Page 17

FRAME GROUP
STORM POLISHER 86221940 12/29/06
3-
4
SERIAL NO.
REF PART NO. PRV NO. QTY DESCRIPTION
FROM
NOTES:
1 86225380
78447 1 TUBE ASSY, HANDLE ADJ
2 86218440
38290 1 HANDLE, POLISHER
3 86136360
57275 1 NUT, M10X1.5 HEX NYLOCK PLTD
4 86221860
51328 2 LINK, HANDLE ADJUST
5 86225720
87203 2 WASHER, 14MMID X 36MMOD
6 86222270
57276 2 NUT, PUSH FLAT RD .51D
7 86226020
89206 2 WHEEL, 5D X 1.25 X 13MMID GRY
8 86137280 87054
2 WASHER, M8 FLAT DIN125A PLT
9 86136640 70262
2 SCR, M8-1.25 HHMS PLTD
10 86274230 70135
2 SCR, M8 X 30 HHMS
11 86224290 730008
2 SPACER, .317ID X .5OD X .44LG
12 86279090 87067
4 WASHER, 5/16 LOCK INT STAR PLT
13 86136710 70698
4 SCR,5/16-18 X 3/4 HHCS GR5 BLK
14 86276570 70691
2 SCR, M6 X 25 HHMS BLK
15 86137340 87211
2 WASHER, M6 FLAT BLK
16 86216600 27871
2 CAP, EXTRUSION
17A 86216320 14341
- BUMPER, EXTRUSION 30.5"
17B 86216330 14371
- BUMPER, EXTRUSION 37.3"
17C 86216340 14372
- BUMPER, EXTRUSION 43.8"
17D 86216350 14373
- BUMPER, EXTRUSION 53.4"
18A 86288430 29211
- DECK, 13 IN POLISHER, BLUE
18B 86288440 29212
-
DECK, 15 IN POLISHER, BLUE
18C 86217600 29213
-
DECK, 17 IN POLISHER, BLUE
18D 86217610 29214
-
DECK, 20 IN POLISHER, BLUE
19 86214930 03111
1
AXLE, MAIN POLISHER
20
86136720 70701
1
SCR, M10 X 90 HHMS
21
86010720 87086
2
WASHER, M10 X 30 PLTD
22
86216920 23206
1
CORDSET, 14/3 X 47", SJT, BLK
23
86224930 730012
1
STRAIN RELIEF, 14/3 STRAIGHT
