Windsor 10090240 - Page 19

MOTOR GROUP
STORM POLISHER 86221940 12/29/06
3-
6
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86217490 27884 1 COVER, MOTOR
2 86220020 500763 1 LABEL, STORM MAIN
3 86222090 53263 1 MOTOR, 1 HP 115V INDUCTION SPT13/15/17/20
4 86223690 70702 3 SCR, M5 X .8 X 15MM BLK
5 86222100 53264 1 MOTOR, 1.5 HP 115V INDUCTION
INCLUDES ITEM
4, 1, 12, & 11
(SP17X/20X)
6 86220030 500764 1 LABEL, STORM DELUXE MAIN
7 86217500 27892 1 COVER, ASM, MOTOR
8 86223680 70700 8 SCR, M5 X .8 X 10MM PHMS BLK
9 86222070 53253 1
MOTOR, 115V 1.75 HP 175/300
RPM
SPDS20
10 86220040 500765 1
LABEL, STORM DUAL SPEED
MAIN
11 86223700 70723 6 SCR, M5 X .8 X 15MM SHCSM
12 86223030 62917 1 PLATE, ADAPTER MOTOR
MOTOR COMPONENTS (NOT SHOWN)
PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
86216710 140411 1 CIRCUIT BREAKER, 20 AMP
SP13/15/17/17X/2
0/20X
86216700 140401 1 CIRCUIT BREAKER, 30 AMP SPDS20
86223390 67488 1 RECTIFIER, 50A 600V BRIDGE SPDS20
86001820 14404 1 BRUSH SET MOTOR (PKG OF 4) SPDS20
86003660 34378 1 FUSE
86003670 34379 1 FUSE HOLDER
86001020 09135 2 BEARING, MOTOR
86135540 27352 1 COUPLING, MTR/GEAR BOX
86225170 730039 1 SWITCH ASM, DUAL SPEED
SPDS20 (FOR 2
SPEED ONLY)
86215410 140416 1 BOOT, CIRCUIT BREAKER
86223510 67489 1 RING, MOTOR SHAFT
86214740 05176 1 ARMATURE, MOTOR REPAIR 53253 SPDS20
86002650 270061 1 CAPACITOR, RUN 30UF
SP13/15/17/17X/2
0/20X
86216610 270062 1 CAPACITOR, START 340UF
SP13/15/17/17X/2
0/20X
86216650 72182 1 CENTRIFUGAL WEIGHT ASSEMBLY
SP13/15/17/17X/2
0/20X
86224890 72183 1 STATIONARY END CAP SWITCH
SP13/15/17/17X/2
0/20X
