Windsor SENSOR XP12 User Manual

PARTS LIST / SENSOR XP12 / 120V
POS
PRODUCT
CODE
REF NO. DESCRIPTION NOTES
1 86407970 5625WI HANDLE COMPLETE, BLACK
2 86372980 5295WI HANDLE GRIP SR BLACK
3 86319140 5359SW GROMMET, BLACK
4 86139130 1260KA CABLE, YELLOW
5 86319160 5113 SWITCH
6 86407990 5160ZG SWITCH CAP, ZINC YELLOW
7 86319180 5161SW SWITCH CAP HOLDER BLACK
8 86139280 5162 CABLE CLAMP
9 86147040 0103ER SCR, M3,9 X 16 MM DIN 7981
10 86137780 0846 ANTISTATIC WIRE
11 86142310 5256ER HANDLE CABLE 3WIRE W/CONNECTOR
12 86147140 0129 SCREW, M4 x 12MM
13 86142300 5187 HANDLE TUBE
14 86147030 0102 SCREW M3,9x13 DIN 7981
15 86142650 5040sb HOSE, SENSOR SILVER
16 86319200 5045sw EXTENSION TUBE, BLACK
17 86408000 5803kg COVER, KARCHER GRAY
18 86145340 5319 SPRING, BAG HOLDER
19 86408010 5706zg COVER RELEASE, ZINC YELLOW
20 86144760 5091 SAFETY CATCH SPRING
21 86144770 5360 SAFETY CATCH
22 86138050 5324 BAG HOLDER.
23 86408020 5800BG FRONT COVER COMPLETE, BASALT GRAY
24 86000500 5300 SENSOR FILTER BAG PACK
25 86005220 5301ER MICRO HYGIENE FILTER
27 86408030 5380BG INTERNAL COVER, BASALT GRAY
29 86139970 1073 CLAMP
30 86141620 5208 FILTER SAFETY CATCH
31 86145320 5210 SPRING (MICOR FILTER CATCH
32 86139290 5164 CABLE CLAMP
33 86408040 5082kg DUST BAG HOUSING LOCKING CATCH, KARCHER GRAY
34 86408050 5098kg LOCK CATCH, KARCHER GRAY
35 86142290 5099 HANDLE LOCK PLATE
36 86143060 0187 LOCK PIN
37 86145350 5146 STOP SPRING (HOOK)
38 86408060 5145bg CARRYING HANDLE, BASALT GRAY
39 86408070 5144kg CABLE HOOK, KARCHER GRAY
40 86408080 5424KG RETAINING RING, KARCHER GRAY
41 86142880 5255ER INTERNAL CABLE 3WIRE LOOSE CON
42 86139320 5266 CABLE CLAMP (FILTER BAG HSNG)
43 86373870 5842 SEAL
46 86144930 5289 SEAL, FILTER TUBE
47 86319290 1491sw UPHOLSTERY NOZZLE, BLACK
48 86319250 1823sw CLIP, DUST BAG HOUSE-SR12, BLACK
49 86145280 5084 SPRING, LOCKING ROD
51 86144910 5163 SEAL, FILTER BAG HOUSING NECK
52 86143120 5083 LOCKING ROD
53 86408090 5085bg DUST BAG HOUS.BUMPER BASE, BASALT GRAY
54 86408100 5215BG DUST BAG HOUSING, SR’S, 3-WIRE, BASALT GRAY
55 86319300 1092sw CREVICE NOZZLE, BLACK
56 86408110 0532EK SWITCH, BLACK / ZINC YELLOW

Windsor SENSOR XP12 Specifications

General

Model	SENSOR XP12
Category	Vacuum Cleaner
Cleaning Path	12 inches
Cord Length	40 feet
Width	12 inches
Power	1200 W
Filter Type	HEPA
