REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86214940 03115 1 AXLE, PAD DRIVER
2 86217510 27913 1 COVER, BEARING
3 86276730 70719 3 SCR, M4 X 8MM PPHMS
4 86004820 48041 1 KEY, 3/16 SQ X 7/8 CRS
5 86223280 64106 1 PULLEY, .625 X 3.45
6 86225730 87218 1 WASHER, M6 (20.5OD X 1.67) PLT
7 86275570 70505 1 SCR, 1/4-20 X 1.00 HHCS GR5
8 86223290 64107 1 PULLEY, BURNISHER
9 86223470 67449 1 RING, 20M EXTERNAL SNAP
10 86222480 66426 1 PAD DRIVER, 20 IN BURNISHER FLEX
11 86246740 51353 1 LOCK, PAD DRIVER BLUE
12 86276740 70720 3 SCR, #10 X 3/8 PPHST TYPE B
13 86006670 70201 8 SCR, 1/4-20 X 3/4 FHCS
14 86223970 09133 1 BEARING, 20MM X 52MM
15 86223480 67450 2 RING, 52MM INTERNAL SNAP
16 86215330 14424 1 BELT, DRIVE 38 IN
17 86223980 09134 1 SEALED BALL BEARING, 25MM X 52MM
To Next Page
