HEATING & AIR CONDITIONING GROUP (CONTINUED)
13,500 BTU COLEMAN ROOF A/C & CEILING ASSEMBLY - EUROPEAN
KEY PART NUMBER U/M DESCRIPTION VENDOR NO.
1 108889-02-01A EA A/C-ROOF, 13,500 TSR 220 IVORY - 7373-597
2 093763-01-712 EA FAN BLADE-CONDENSER 6733-3221
3 105620-01-706 EA FOOT PACKAGE-COMPRESSOR, 3 PER PACKAGE 6759-3081
4 108889-02-701 EA MOTOR - 115V, 60HZ 1468-3059
5 108889-01-706 EA IMPELLOR 1472-1041
6 108889-01-708 EA CAPACITOR-FAN, (7.5MFD.370U) 1499-5461
108889-01-710 EA FILLER PAD-COND AIR SEAL 6759A3971
7 108889-01-711 EA GASKET PACKAGE 6792-3301
8 108889-01-715 EA MOTOR MOUNT & SHAFT SEAL KIT 6792-3361
9 063903-01-700 EA SHROUD 6759-4601
10 108889-01-703 EA CONDENSER COIL 1452-1301
11 108889-02-700 EA COMPRESSOR, TECUMSEH 1452-2029
12 108889-01-707 EA CAPACITOR-RUN, COMPRESSOR-25MFD/370 1499-5661
108889-02-703 EA RELAY-START 1497-4141
KEY PART NUMBER U/M DESCRIPTION VENDOR NO.
13 108889-01-709 EA EVAPORATOR COIL 1452-1311
108889-01-714 EA DISCHARGE LINE ASSEMBLEY 6792-531
108889-01-712 EA REDUCER-SUCTION LINE, (3/8" X 1/2") 1215-2161
108889-01-713 EA SUCTION LINE, (3/8" OD X .032" WALL) 6792-130
108889-02-702 EA CAPACITOR-START 1497-0891
093306-01-701 EA DECAL PACKAGE-LEFT & RIGHT 6798B3591
105620-01-705 EA OVERLOAD 6759-3791
102289-01-000 EA SPRING-SCREW, ROOF A/C GASKET - 6757-150
108892-01-01A EA CEILING ASM-A/C DUCTED - 7330-730 IV
108892-01-700 EA PLUG ASSEMBLY 7330-540
108892-01-701 EA BOARD-TERMINAL 7330-3201
108892-01-702 EA BOARD-PRINTED CIRCUIT 7330A3211
108892-01-703 EA FILTER 6798A3761
108892-01-704 EA GRILLE (PLASTIC) 6798-3041
108892-01-705 EA SMALL PARTS PKG 7330A6101
9
10
4
8
11
3
2
13
5
7
12
6
1
