HEATING & AIR CONDITIONING GROUP (CONTINUED)
COLEMAN ROOF AIR 13,500 BTU (US, CSA)
KEY PART NUMBER U/M DESCRIPTION VENDOR NO.
1 108889-01-03A EA A/C - ROOF - 13,500 TSR HO BUFF - 7333A888
2 093763-01-712 EA FAN BLADE - CONDENSER - 6733-3221
3 105620-01-706 EA FOOT PKG - COMPRESSOR - 3 PER PACKAGE 6759-3081
4 108889-01-705 EA MOTOR (115 - 60HZ) 1468-3049
5 108889-01-706 EA IMPELLOR 1472-1041
6 093763-01-704 EA CAPACITOR - FAN 1499-3461
7 108889-01-711 EA GASKET PACKAGE 6792-3301
8 108889-01-715 EA MOTOR MOUNT & SHAFT SEAL KIT 6792-3361
9 108889-01-702 EA SHROUD (BUFF/ BUFF) LESS LOGO 6759-6411
10 108889-01-703 EA CONDENSER COIL 1452A1301
11 105620-01-704 EA COMPRESSOR - RH & LH 1450-2009
108889-01-704 EA OVERLOAD (MRA#98693) 6749-3541
12 108889-01-707 EA RUN CAPACITOR (COMP-25MFD/ 370) 1499-5661
13 108889-01-709 EA EVAPORATOR COIL 1452A1311
9
10
4
8
11
3
2
13
5
7
12
6
1
KEY PART NUMBER U/M DESCRIPTION VENDOR NO.
091225-01-709 EA START RELAY 1497-4131
091225-01-710 EA START CAPACITOR 1497-0881
093306-01-701 EA DECAL PKG - LEFT & RIGHT 6798B3591
108889-01-710 EA FILLER PAD - COND AIR SEAL 6759A3971
108889-01-712 EA SUCTION LINE REDUCER (3/8 X 1/2) 1215-2161
108889-01-713 EA SUCTION LINE (3/8 OD X .032 WALL) 6792-130
108889-01-714 EA DISCHARGE LINE ASM. 6792-531
108892-01-01A EA CEILING ASM - A/C DUCTED - 7330-730 IV
108892-01-700 EA PLUG ASSEMBLY 7330-540
108892-01-701 EA TERMINAL BOARD 7330-3201
108892-01-702 EA PRINTED CIRCUIT BOARD 7330-3211
108892-01-703 EA FILTER 6798A3761
108892-01-704 EA GRILLE (PLASTIC) 6798-3041
108892-01-705 EA SMALL PARTS PKG 7330A6101
108892-01-706 EA COIL - SENSOR 7330-6111
110403-01-F31 EA SPACER ASM - RETURN AIR -OAK
117238-01-01A EA THERMOSTAT - A/C AND FURNACE - 7330-3371
117238-02-01A EA THERMOSTAT - A/C ONLY - 7330-3381
088238-01-000 EA COVER - SWITCH - A/C SELECTOR - FRONT TO REAR A/C
073937-03-000 EA SWITCH - ROTARY SELECTOR - 3 DECK - A/C - CA20-USA892
088238-02-000 EA COVER - SWITCH - A/C SELECTOR FOR FRONT OR REAR
