SECTION 10 –
SLIDEOUT ROOMS AND LEVELING
10-10
SLIDEOUT EMERGENCY
RETRACTION
If the slideout mechanism is malfunctioning
and the room will not retract using the interior
control switch or exterior control panel, you may
need to access the slideout motors and manually
push the room in to the travel position.
There are two slideout motors equipped on the
end wall of each slideout room. Pull back wipe
seal to access motors.
Push-In Procedure
1. Pull back wipe seal to access slideout motor.
2. Using a flat-head screwdriver, push bottom of
slideout motor UP to disengage
(approximately 1/2” from base).
Repeat on opposite slideout motor.
3. Push slideout room in to travel position,
ensuring both sides are relatively even.
NOTE: Several people may be needed to push
the room in.
4. When the slideout room is fully retracted,
secure the room with a support item (e.g. 2x4
wood board) above the interior slideout room
to secure room during travel.
NOTE: For larger slideout rooms, place a travel
support item on each end of the interior
slideout room.
Slideout Motor
(Located behind slideout wipe seal)
• Use a screwdriver to push slideout motor
UP (disengage).
• Ensure slideout motor is disengaged
approximately 1/2” from base.
To Next Page
