Wintriss SmartPAC 2 Instruction Sheet

Upgrading from Original SmartPAC or SmartPAC 2 to SmartPAC PRO 1145200
Instruction Sheet 11
SmartPAC 2

SmartPAC PRO RTS
Signal Type
Connector
Pin
number
Connector
Pin
number
Done

MultiPAC (Special Port - Optional)
+RXD3
TB104
224

TB7
224
-RXD3
TB104
225

TB7
225
TXD3
TB104
226

TB7
226
+TDX3
TB104
227

TB7
227
-TDX3
TB104
228

TB7
228
GRD.
TB104
229

TB7
229
PACNet (Optional)
GRD.
TB104
229

TB7
229
+RXD4
TB104
230

TB7
230
-RXD4
TB104
231

TB7
231
TXD4
TB104
232

TB7
232
+TXD4
TB104
233

TB7
233
-TXD4
TB104
234

TB7
234
NOTE: Connect all shields / ground wires to chassis ground
