13
WIPEKET
DE
EN
FR
+49 (0)7158 9181 500 info
@
topregal.com www.topregal.com
Nr. Teilenummer Name Anzahl
1 6402240401 Antriebsrad 2
2 6402240402 Platte der Antriebsachse 2
3 6402240403 Antriebsachse 1
4 6402240404 Befestigungsblock 4
5 6402240405 Saugleistenhebel 1
6 6402240406 Rahmen 1
Nr. Teilenummer Name Anzahl
1 6402240801 Frontleiste 3 1
2 6402240802 Frontleiste 4 1
3 6402240803 Frontgummi 2 2
4 6402240804 Korpus 2
5 6402240805 Halterung 1 1
6 6402240806 Gummi 2 2
7 6402240807 Hintere Platte 1 2
8 6402240808 Hintere Platte 2 2
9 6402240809 Drehrad 2
10 6402240810 Rolle 2
11 6402240811 Rad 2
HINTERE ANTRIEBSEINHEIT
SAUGLEISTE
