WUC-712
REMOTE UNIVERSAL ETHERNET
All rights reserved to Wirebus © 2011 – 2018
Apresentação
The Universal Remote Ethernet WUC-712 is
designed to promote versatility and robustness in
industrial plants.
With is processing core based in the ARM®
technology, the WUC-712 offers speed and
accessibility to field variables through the Modbus
TCP protocol over Ethernet and also through the
Modbus RTU protocol over the RS-485 physical
interface, thus enabling the acquisition of 16 inputs
from several kind of signals such as
thermocouples, RTD resistive sensors, current,
tension, frequency and logical levels.
The available inputs and product features are
described below:
Thermocouples type J, K, T, R, S, E, N, B (ITS-90) with cold junction compensation
RTD type Pt100 (two or three wires)
Current 0-20 mA and 4-20 mA
Voltage 0 – 75 mV, 0 – 5 V or 0 – 10 V
Logic level maximum amplitude 12 Vdc
Frequency up to 10 kHz with 4 simultaneous channels with 0.3 V to 50 V sensibility
Two digital inputs isolated up to 30 Vdc for alarm acknowledgment
Two alarm levels per channel, configurable (high, low, or differential) with hysteresis and delay of 1 to
10 seconds
Two relay outputs for alarm status
Fully detachable (plug-in type) connection to the terminal block
Integrated Ethernet switch
The WUC-712 is configured by the universal Wirebus configuration tool WireConfig.
