3
Installation
• Route speaker cables from each listening zone to
the speaker selector
• Route speaker cables from the amplifier to the
speaker selector
• Remove approximately 8" of the outer jacket from
speaker cable (if necessary)
• Strip approximately 3/8" of insulation from each
conductor and twist the exposed strands together
to avoid fraying
• Press the push terminal and insert the conductor;
release to make contact
• Set Impedance Protection to ON or OFF as
necessary
4
Specifications
Protection
Circuit
Protection
ON
Dimensions
SS4
2 x 10 ohm
15
watts/channel
140
watts/channel
70
watts/channel
8.5" x 4.4" x
1.93"
SS6
2 x 10 ohm
15
watts/channel
140
watts/channel
70
watts/channel
17" x 4.4" x
1.93"
SS8
3 x 10 ohm
15 watt/channel
200
watts/channel
100
watts/channel
17" x 4.4" x
1.93"
Warranty
This Wired Home product is warranted free from defects in
material and workmanship for a period of One Year from the
date of purchase. Wired Home will at their discretion, repair,
replace or credit the faulty unit unless otherwise specified by
contractual agreement. Any faulty unit that is no longer in
production will be replaced with a similar or equivalent unit.
Warranty registration is not required, but purchasers are asked
to retain their receipt as proof of purchase. Warranty does not
apply to misuse, abuse, neglect, accident, improper use, etc.
