P.O. Box 10 • Oregon, WI 53575 • Ph: 608.835.3106 • Fx: 608.835.8273 • wiscoind.com • wiscomade.comP.O. Box 10 • Oregon, WI 53575 • Ph: 608.835.3106 • Fx: 608.835.8273 • wiscoind.com • wiscomade.comP.O. Box 10 • Oregon, WI 53575 • Ph: 608.835.3106 • Fx: 608.835.8273 • wiscoind.com • wiscomade.comP.O. Box 10 • Oregon, WI 53575 • Ph: 608.835.3106 • Fx: 608.835.8273 • wiscoind.com • wiscomade.com
WIRING DIAGRAM:EXPLODED VIEW:PARTS LIST:PARTS LIST:
MODEL 520
ITEM # PART # DESCRIPTION
1 0022845
DIGITAL TIMER Requires (1)AAA battery; Not Included
2 0022671
CONTROL KNOB
3 0022843
POWER SWITCH
4 0022841
REGULATING THERMOSTAT
5 I013754
CONTROL DECAL
6 0022809SK
REAR FOOT SERVICE KIT
7 0023054SK
SIDE FOOT SERVICE KIT (Incl. Foot, insert, lockwasher, nut & screw)
8 0022801
POWER CORD
9 0022667
STRAIN RELIEF
10 0022832
HI-LIMIT THERMOSTAT
11 0022662
FAN BLADE
12 0023057SK
BOTTOM FOOT SERVICE KIT
13 0022825
THERMAL INSULATOR
14 0022802
BLOWER MOTOR
15 0022824
HEATING ELEMENT
16 0022844
SINGLE COOKIE PAN
17 0022833
INTERNAL SUPPORT RACK
18 0022810SK
DOOR ASSEMBLY SERVICE KIT
19 0022808
MAGNET
*
0022840CR
COOLING RACK
*
00520PS3
3 COOKIE PANS BOXED SET
*
0022847
500 COUNT PARCHMENT PAPER 520
