p. 54
6 Insert the handlebars into the battery tube in
the direction shown (it should not force and
should slide easily). The holes in the
handlebars must be aligned with the holes in
the stem.
7 Finish the assembly by screwing back in the
two screws of the hook.
2.5 Rear light: installation and use
Your rear light is powered by 2 batteries CR2032.
➢ Replacement
When the LED on the top of the light flashes, the batteries must be replaced
immediately so that a light is always available.
1. Unclip the lamp from its holder
2. Insert the batteries with the correct polarity
3. Reclip the light, making sure it is secure.
If it is incorrectly clipped in, it could come off due to
vibrations. Water could also get in and damage the fire.
