p.17
2.4 Assembling the scooter
1°)Unfold the scooter (unfolding instructions p.19).
2°)Insert the handlebars into the stem tube, being careful not to pinch the cables
(this should not force when inserted, and should slide easily). Don't forget to connect
the cable between the stem and the handlebars. Orient the handlebars as shown
below.
3°)Insert and tighten the six screws (provided) holding the handlebars to the stem
using the hex key (provided).
4°)Check that the handlebars do not move in relation to the stem. If the handlebars
are still moving relative to the stem, tighten the six screws and recheck if you see
any movement between the two.
5°)Check that the tire pressure is between [2 and 2.4 bars] in order to avoid
premature mechanical wear of the product (pump not supplied).
To Next Page
