Working
Radio remote control or the remote control of cooker hoods (fig. 9).
Technical data:
• Alkaline battery powered: 12V mod 23A
• Operating frequency: 433.92 MHz
• Max. consumption: 25 mA
• Combination: 4096
• Operating temperature: - 20 + 55°C
Working description:
To light the cooker hood on or to light it off press the button
To increase the speed up to the fourth one press the button
To reduce the speed up to the second one press the button
To go from a high speed back to the first one press twice the button
To give power to the lights or to shut them down press the button
To set the timer up press the button
The LED on the right side will start to flash (every 5 seconds), the hood will
work for 10 minutes at the selected speed and then it lights automatically off.
If the client increases or reduces the speed while the timer is on, this is
automatically stopped.
WORKING
Remark: At every selected function, the LED lights on accordingly.
At first ignition, keep pressed the lighting button for 5 seconds.
