Hook TV on to adapter plate. Secure bracket to adapter plate with M5 x 10mm secur-
ing screws (Q) and washers (R and S).
ТВ со смонтированным ТВ адаптером навесьте на настенную часть кронштейна.
Зафиксируйте винтами М5 х 10 мм и шайбами R и S.
Hang TV sur la plaque adaptatrice. Fixez le support sur la plaque adaptatrice avec
connecteur M5 x 10 mm vis de xation (Q) et washer (R et S).
6
МОНТАЖ ТВ
7
Level TV to desired position then tighten screw (Q).
Настройте горизонтальное положение ТВ и затяните винт Q.
Niveau TV à la position désirée puis serrer les vis (Q) de xation.
ФИКСАЦИЯ И ВЫРАВНИВАНИЕ ТВ
7
R
S Q
