WNC DHUM-E997 - Bluetooth Specifications

MODEL: DHUM-E997
Wistron Neweb Corporation
12 of 17
 2 Nss: 130(144.444) Mbps maximal
 40MHz BW
 1 Nss: 135(150) Mbps maximal
 2 Nss: 270(300) Mbps maximal
 802.11ac: @800GI(400GI)
 80MHz BW
 1 Nss: 390(433.3) Mbps maximal
 2 Nss: 780(866.7) Mbps maximal
Security
WEP, WPA ,WPA2 ,AES, TKIP
Operation
temperature
-10
o
~ 60
o
C
Storage
temperature
- 35
o
~ 70
o
C ,R.H:90%（non-condensing）
Antenna
 2 PIFA printed ANTs
4-4.BT Portion
Item
Key specifications
Main chipset
 Marvell 88W8997
Compliance
 Bluetooth 4.2 LE
Frequency
range
 2400 ~ 2483.5MHz
Initial carrier
frequency
tolerance
 +/- 40kHz (typical)
Modulation
technique
 Frequency hopping, 1600 hops/sec
Channel
spacing
 1MHz
Channels
support
 79 channels
Power
consumption
@25
o
C
Description
Avg (mA)
Max (mA)
BLE Tx peak (@10dBm)
43
56
BLE Rx peak
29
36
SCO HV3 Tx peak (@10dBm)
46
57
SCO HV3 Rx peak
27
36
ACL DH1 average (data pump)
24
29
ACL 2-DH3 average (data pump)
27
34
ACL 3-DH5 average (data pump)
29
36
Note：
※The maximum current consumption would be impacted by radiation environment and the driver
mechanism.
Output power
(dBm)
 Output Power0~10dBm（Class I Device）
Sensitivity
 -80 dBm (typ.) for pi/4-DQPSK, 0.1%BER
Operation
temperature
 -10
o
~ 60
o
C
Storage
temperature
 -35
o
~ 70
o
C , R.H. : 90%（non-condensing）
Antenna
 PIFA printed ANT
