11
G
GCongratulations on the purchase of your WOLF product
Contents
Technical data . . . . . . . . . . . . . . . . . . . .11
Safety instructions . . . . . . . . . . . . . . . . . .12
Assembly . . . . . . . . . . . . . . . . . . . . . . .13
Operation . . . . . . . . . . . . . . . . . . . . . . .13
Maintenance . . . . . . . . . . . . . . . . . . . . .14
Spare parts . . . . . . . . . . . . . . . . . . . . . .14
Faults and how to remedy . . . . . . . . . . . . . .15
Guarantee terms . . . . . . . . . . . . . . . . . . .15
EC Declaration of Conformity. . . . . . . . . . . . 108
An overview of the equipment features
–
central cutting height adjustment
– Minimum space requirement (transport and storage) "just
stand it on the basket"
– will fit into a SMART when folded down
– Collection basket level indicator
–
high quality materials, excellent workmanship and attracti-
ve design.
– Ready-to-use: from 0 to mowing in 30 seconds
– tough and capable motor
Technical data
Read the user manual carefully and familiarise yourself
with the operating elements and the correct operation
of the equipment. The operator is responsible for acci-
dents involving other persons and their property. Ob-
serve the notes, explanations and regulations.
Never allow children or other persons who are not fa-
miliar with the operating instructions to use the lawn-
mower.Young persons under the age of 16 may not
use the equipment.Local regulations can limit the mini-
mum age of the operator.
The right to make technical modifications is reserved
D Noise level measurement at the ear of the operator in accor-
dance with EN 836
E
Vibration measured at the guide bar, with operator in accor-
dance with EN 1033 and EN 836.The estimated acceleration
is, typically:
2.32 E-1
Type 4905 ...
A 94 cm
B 34 cm
C 36 cm
D LP 76 dB (A)
E a
hw
≤ 2,5 m/s
2
Nominal power rating 1000 W
Current intensity 5,6 A
Mains voltage 230 VAC
Collection basket volume 25 l
Cutting width 32 cm
Cutting height 20, 32, 45, 60 mm
Weight 12 kg
